1975 Corvette Factory Wiring Diagram Manual

$8.95

Part # LIT-1425

In Stock Now
In Stock
add to cart
Product Specifications
Part # LIT-1425
Year 1975
Application Corvette
Color See Photo
Availability In Stock, Available — This means the part is in our building ready to ship!
Description 1975 Chevrolet Corvette wiring diagram manual. This wiring manual covers all typical wiring harness circuits including headlight harness, underdash harness, taillight harness, Air Conditioning, power windows, and all fuses. Our manual can be very helpful when tracking down electrical problems. Very high quality printing. Highly Recommended for all restorers.
